Coordination Compounds Formula Sheet — JEE Main Chemistry

Every key Coordination Compounds formula, definition and theorem for JEE Main Chemistry in one place — with common examiner traps and worked examples. Free to read; blurt from memory, then check your gaps.

Syllabus — topics coveredNTA · 12 sub-topics

Introduction to coordination compounds
Werner's theory
Ligands
Coordination number
Denticity
Chelation
IUPAC nomenclature of mononuclear coordination compounds
Isomerism
Bonding: Valence bond approach
Basic ideas of Crystal field theory
Colour and magnetic properties
Importance of coordination compounds

Werner's Theory & Key Terms

Coordination compound: A compound containing a

coordination entity

— a central metal atom/ion bonded to a fixed number of ions or neutral molecules (ligands) that

retains its identity

even in solution, e.g.

K_{4} [Fe (CN)_{6}]

gives

K^{+}

and

[Fe (CN)_{6}]^{4 -}

, not free

F e^{2 +}

and

C N^{-}

Annotated structure of hexaamminecobalt(III) chloride: a central Co atom bonded to six NH3 ligands inside the coordination sphere (square brackets, charge 3+), with three chloride counter ions outside; coordination number 6, oxidation number of cobalt +3. — Anatomy of $[Co (N H_{3})_{6}] C l_{3}$ : $Co$ and its six $N H_{3}$ ligands form the complex ion $[Co (N H_{3})_{6}]^{3 +}$ (the coordination sphere, written inside $[]$ ); the three $C l^{-}$ outside are counter ions. CN $= 6$ , oxidation number of Co $= + 3$ .

★ Remember · Werner's two valences

Primary valence

= oxidation number; ionisable, satisfied by

anions

(the counter ions).

Secondary valence

= coordination number; non-ionisable,

fixed and directional

, satisfied by ligands inside the square bracket.

🎯 Exam · Double salt vs complex

double salt

(e.g. Mohr's salt

FeS O_{4} \cdot (N H_{4})_{2} S O_{4} \cdot 6 H_{2} O

, alum) dissociates

completely

into simple ions in water. A

complex

keeps its coordination ion intact — that is the key difference.

Core vocabulary

▸ $Central atom$ accepts electron pairs ⇒ a $Lewis acid$ ; the ligand is the donor (Lewis base).
▸ $Coordination number (CN)$ = number of ligand donor atoms σ-bonded to the metal (π bonds not counted).
▸ $Coordination sphere$ = metal + ligands inside $[]$ ; ions outside are $counter ions$ .
▸ $Oxidation number$ = charge on metal if every ligand (with its shared pair) is removed; shown as a Roman numeral.
▸ $Shape$ is fixed by CN: CN $2 \to$ linear, CN $4 \to$ tetrahedral or square planar, CN $6 \to$ octahedral (the commonest).

Homoleptic vs heteroleptic

▸ $Homoleptic$ : one kind of ligand, e.g. $[Co (N H_{3})_{6}]^{3 +}$ .
▸ $Heteroleptic$ : more than one kind, e.g. $[Co (N H_{3})_{4} C l_{2}]^{+}$ — these can show geometrical isomerism (Page 4).

🚫 Examiner Trap · Examiner traps

(1)

Primary valence

=

oxidation number (ionisable, anions outside);

secondary valence

=

coordination number (fixed, directional, ligands inside

[]

). (2) A

double salt

dissociates fully; a

complex

keeps its ion intact. (3) CN counts

σ

-bonded

donor atoms

(

π

not counted). (4) Central atom

=

Lewis acid (acceptor), ligand

=

Lewis base (donor).

Ligands, Denticity & Chelation

Ligand & denticity: A

ligand

is an ion/molecule that donates a lone pair to the central atom.

Denticity

is the number of donor atoms a single ligand actually uses to bind the metal.

Unidentate

C l^{-}, H_{2} O, N H_{3}, C N^{-}

— 1 donor

Didentate

en,

C_{2} O_{4}^{2 -}

(ox) — 2 donors

Hexadentate

EDT A^{4 -}

— 2 N

+

4 O donors

🎯 Exam · Ambidentate ligands

Can attach through

either

of two donor atoms:

N O_{2}^{-}

binds via N (

nitrito-N

- N O_{2}

) or via O (

nitrito-O

- ONO

);

SC N^{-}

via S (

thiocyanato

) or N (

isothiocyanato

- NCS

). They cause linkage isomerism (Page 4).

★ Remember · Chelate effect

A di-/polydentate ligand that grips the metal through two or more donor atoms forms a

ring

(a chelate). Chelate complexes are

more stable

than similar ones with unidentate ligands — e.g.

[Ni (en)_{3}]^{2 +}

is more stable than

[Ni (N H_{3})_{6}]^{2 +}

Counting coordination number

▸CN counts $donor atoms$ , not ligands: in $[Fe (C_{2} O_{4})_{3}]^{3 -}$ and $[Co (en)_{3}]^{3 +}$ , CN $= 6$ (each didentate ligand donates twice).
▸ $[PtC l_{6}]^{2 -}$ : CN $= 6$ ; $[Ni (N H_{3})_{4}]^{2 +}$ : CN $= 4$ .
▸5- and 6-membered chelate rings are the most stable.

🚫 Examiner Trap · Examiner traps

(1) CN counts

donor atoms

, not ligands:

[Co (en)_{3}]^{3 +}

has CN

= 6

(en is didentate). (2)

Ambidentate

ligands bind via either of two atoms (NO

_{2}^{-}

: N

=

nitrito-N, O

=

nitrito-O; SCN

^{-}

: S vs N). (3)

Chelate effect

: ring-forming polydentate ligands give extra stability. (4) 5- and 6-membered chelate rings are the most stable.

IUPAC Nomenclature

Writing the formula

▸ $Central atom first$ , then ligands in $alphabetical$ order (charge does not matter).
▸Enclose the whole entity in square brackets; polyatomic/abbreviated ligands in parentheses, e.g. $[Co (en)_{2} C l_{2}]^{+}$ .
▸Net charge is written as a right superscript outside the bracket.

Naming the complex

▸ $Cation named first$ (whether complex or simple), then the anion.
▸Within the entity, ligands go $alphabetically$ before the metal (reverse of the formula order).
▸Anionic ligands end in $-o / -ido$ ( $C l^{-} =$ chlorido, $C N^{-} =$ cyanido, $O H^{-} =$ hydroxido); neutral: $H_{2} O =$ aqua, $N H_{3} =$ ammine, $CO =$ carbonyl, $NO =$ nitrosyl.
▸Oxidation number of the metal in $Roman numerals$ in parentheses, no space.

🎯 Exam · Prefixes & anionic complexes

Use

di, tri, tetra

for simple ligands;

bis, tris, tetrakis

(with the ligand in parentheses) when the ligand name already contains di/tri, e.g. bis(ethane-1,2-diamine). If the

complex ion is an anion

, the metal ends in

-ate

: ferrate (Fe), cuprate (Cu), cobaltate, zincate, argentate, aluminate.

[Cr (N H_{3})_{3} (H_{2} O)_{3}] C l_{3}

triamminetriaquachromium(III) chloride

[Co (en)_{3}]_{2} (S O_{4})_{3}

tris(ethane-1,2-diamine)cobalt(III) sulphate

K_{3} [Fe (C_{2} O_{4})_{3}]

potassium trioxalatoferrate(III)

[Ni (CO)_{4}]

tetracarbonylnickel(0)

⚠️ Watch out · Common slips

Order ligands alphabetically by ligand

name

, ignoring the multiplying prefix (di-/tri-). Never write the number of cations/anions for an ionic compound — 'cobalt(III) sulphate', not 'dicobalt tris-sulphate'.

🚫 Examiner Trap · Examiner traps

(1) FORMULA: central atom first, ligands alphabetical; NAME: ligands alphabetical

before

the metal (opposite order). (2) Anionic ligands end

-o/-ido

(chlorido, cyanido); if the complex ION is an anion the metal ends

-ate

(ferrate, cuprate). (3) Use bis/tris/tetrakis when the ligand name already has di/tri (en). (4) Alphabetise by ligand NAME, ignoring the multiplier prefix.

Isomerism in Coordination Compounds

Stereoisomers of complexes: cis/trans square-planar pairs and non-superimposable optical isomers.

★ Remember · Geometrical (cis / trans, fac / mer)

Arises in heteroleptic complexes. Square-planar

[M X_{2} L_{2}]

and octahedral

[M X_{2} L_{4}]

show

cis

(adjacent) and

trans

(opposite).

[M a_{3} b_{3}]

shows

fac

(3 on one face) and

mer

(3 on a meridian).

Tetrahedral

complexes show

no

geometrical isomerism.

🎯 Exam · Optical (d / l enantiomers)

Non-superimposable

mirror images

that rotate plane-polarised light — d (right) and l (left). Common in octahedral chelates:

[Co (en)_{3}]^{3 +}

is chiral; for

[PtC l_{2} (en)_{2}]^{2 +}

only the

cis

isomer is optically active (trans has a plane of symmetry).

Complex type	Geometrical	Total stereoisomers
$[M a_{2} b_{2}]$ tetrahedral	0	0
$[M a_{2} b_{2}]$ square planar	2 (cis, trans)	2
$[Mabcd]$ square planar	3	3
$[M a_{4} b_{2}]$ octahedral	2 (cis, trans)	2
$[M a_{3} b_{3}]$ octahedral	2 (fac, mer)	2
$[M a_{2} b_{2} c_{2}]$ octahedral	5	6 (all-cis is chiral)
$[M (AA)_{2} b_{2}]$ octahedral	2 (cis, trans)	3 (cis is chiral)
$[M (AA)_{3}]$ octahedral	0	2 ( $d$ , $l$ )

Structural isomerism: Isomers with the

same

formula but

different

bonds/connectivity — four standard types in coordination chemistry.

Ionisation

[Co (N H_{3})_{5} S O_{4}] Br

[Co (N H_{3})_{5} Br] S O_{4}

Linkage

- N O_{2}

(yellow) /

- ONO

(red), ambidentate

Coordination

[Co (N H_{3})_{6}] [Cr (CN)_{6}]

[Cr (N H_{3})_{6}] [Co (CN)_{6}]

Solvate / hydrate

[Cr (H_{2} O)_{6}] C l_{3}

[Cr (H_{2} O)_{5} Cl] C l_{2} \cdot H_{2} O

How to tell them apart

▸ $Ionisation$ : counter ion and a ligand swap ⇒ different ions in solution (test with $BaC l_{2}$ / $AgN O_{3}$ ).
▸ $Linkage$ : same ambidentate ligand, different donor atom.
▸ $Solvate$ : water inside the sphere vs free in the lattice.

🚫 Examiner Trap · Examiner traps

(1)

Tetrahedral

complexes show NO geometrical isomerism. (2) cis/trans for

[M X_{2} L_{2}]

(sq planar) and

[M X_{2} L_{4}]

; fac/mer for

[M a_{3} b_{3}]

. (3) Optical: only the

cis

isomer of

[PtC l_{2} (en)_{2}]^{2 +}

is active (trans has a symmetry plane). (4) Ionisation isomers give DIFFERENT ions in solution (test with AgN

O_{3}

/BaC

l_{2}

Valence Bond Theory (VBT)

VBT of complexes: The metal ion provides

hybrid orbitals

(mixing

(n - 1) d

, ns, np, nd) of a definite geometry; each accepts a

lone pair

from a ligand to form a coordinate bond. The hybridisation fixes the shape.

Orbital box diagrams contrasting the inner-orbital low-spin d2sp3 hexaamminecobalt(III) ion with the outer-orbital high-spin sp3d2 hexafluorocobaltate(III) ion, plus a table mapping coordination number and hybridisation to geometry — Inner ( $d^{2} s p^{3}$ ) vs outer ( $s p^{3} d^{2}$ ) orbital octahedral complexes.

CN	Hybridisation	Geometry	Example
4	$s p^{3}$	tetrahedral	$[NiC l_{4}]^{2 -}$ , $[Ni (CO)_{4}]$
4	$dsp^{2}$	square planar	$[Ni (CN)_{4}]^{2 -}$ , $[PtC l_{4}]^{2 -}$
5	$s p^{3} d$	trig. bipyramidal	$[Fe (CO)_{5}]$
6	$d^{2} s p^{3}$ / $s p^{3} d^{2}$	octahedral	inner / outer orbital

🎯 Exam · Inner vs outer orbital

Inner orbital

(

d^{2} s p^{3}

, uses inner

(n - 1) d

): strong-field ligand pairs electrons ⇒

low spin

, e.g.

[Co (N H_{3})_{6}]^{3 +}

(diamagnetic).

Outer orbital

(

s p^{3} d^{2}

, uses outer nd): weak-field ligand keeps electrons unpaired ⇒

high spin

, e.g.

[Co F_{6}]^{3 -}

(4 unpaired).

Spin-only magnetic moment

μ = n (n + 2) BM

n =

unpaired electrons. Measured

μ

reveals the hybridisation and geometry.

Standard CN-4 cases

▸ $[NiC l_{4}]^{2 -}$ : $s p^{3}$ , $tetrahedral$ , paramagnetic (2 unpaired).
▸ $[Ni (CN)_{4}]^{2 -}$ : $dsp^{2}$ , $square planar$ , diamagnetic (strong-field $C N^{-}$ pairs the $d^{8}$ ).
▸ $[Ni (CO)_{4}]$ : $s p^{3}$ , tetrahedral, diamagnetic (Ni in zero state, $3 d^{10}$ ).

⚠️ Watch out · Limitations of VBT

It does

not

explain colour, give quantitative magnetic data, predict tetrahedral vs square-planar reliably, or distinguish strong- and weak-field ligands — that needs Crystal Field Theory (Page 6).

🚫 Examiner Trap · Examiner traps

(1)

Inner-orbital

d^{2} s p^{3}

(uses

(n - 1) d

)

=

low spin;

outer-orbital

s p^{3} d^{2}

(uses nd)

=

high spin. (2)

μ = n (n + 2)

counts unpaired electrons. (3)

[NiC l_{4}]^{2 -}

s p^{3}

tetrahedral (paramagnetic) but

[Ni (CN)_{4}]^{2 -}

dsp^{2}

square planar (diamagnetic). (4) VBT can't explain colour or strong/weak-field — use CFT.

Crystal Field Theory (CFT)

Crystal Field Theory: An

electrostatic

model: ligands are point negative charges/dipoles. Their field lifts the degeneracy of the five d orbitals — orbitals pointing

at

the ligands are raised, those pointing

between

them are lowered.

Octahedral

e_{g} ↑ + \frac{3}{5} Δ_{o}

t_{2 g} ↓ - \frac{2}{5} Δ_{o}

Tetrahedral

inverted (e low,

t_{2}

high),

Δ_{t} = \frac{4}{9} Δ_{o}

★ Remember · Spectrochemical series

Ligands by increasing field strength:

I^{-} < B r^{-} < SC N^{-} < C l^{-} < F^{-} < O H^{-} < C_{2} O_{4}^{2 -} < H_{2} O < N H_{3} < en < C N^{-} < CO

. Left = weak-field; right = strong-field.

d6 electron filling under a weak field giving high spin t2g4 eg2 with 4 unpaired electrons versus a strong field giving low spin t2g6 with zero unpaired, plus a colour wheel showing observed colour as the complement of the absorbed light — $d^{6}$ high-spin vs low-spin filling; colour as the complement of absorbed light.

🎯 Exam · High spin vs low spin

Compare

Δ_{o}

with the pairing energy P. If

Δ_{o} < P

(weak field) the 4th d electron enters

e_{g}

⇒

high spin

. If

Δ_{o} > P

(strong field) it pairs in

t_{2 g}

⇒

low spin

. Tetrahedral

Δ_{t}

is small, so tetrahedral complexes are

almost always high spin

Worked spin counts (

d^{6}

, octahedral)

▸Weak field ( $[Co F_{6}]^{3 -}$ , $[Fe (H_{2} O)_{6}]^{2 +}$ ): $t_{2 g}^{4} e_{g}^{2}$ , 4 unpaired ⇒ paramagnetic.
▸Strong field ( $[Co (N H_{3})_{6}]^{3 +}$ , $[Fe (CN)_{6}]^{4 -}$ ): $t_{2 g}^{6} e_{g}^{0}$ , 0 unpaired ⇒ diamagnetic.

Crystal field stabilisation energy (CFSE)

CFSE_{oc t} = (- 0.4 n_{t_{2 g}} + 0.6 n_{e_{g}}) Δ_{o}, CFSE_{t e t} = (- 0.6 n_{e} + 0.4 n_{t_{2}}) Δ_{t}

Low-spin

d^{6}

- 2.4 Δ_{o}

; high-spin

d^{6}

- 0.4 Δ_{o}

. If asked, add

+ P

for each extra pair the strong field forces (low-spin

d^{6}

- 2.4 Δ_{o} + 2 P

🚫 Examiner Trap · Examiner traps

(1) Octahedral:

e_{g}

UP (

+ \frac{3}{5} Δ_{o}

t_{2 g}

DOWN; tetrahedral is INVERTED with

Δ_{t} = \frac{4}{9} Δ_{o}

(small). (2) High vs low spin: compare

Δ_{o}

with pairing energy P — strong field (

Δ_{o} > P

)

=

low spin. (3) Tetrahedral complexes are

almost always high spin

. (4) Spectrochemical series: CO/CN

^{-}

/en strong, I

^{-}

/Br

^{-}

weak — memorise the order.

Colour, Carbonyls, Stability & Applications

Colour of complexes: A partially filled d ion absorbs visible light to promote an electron

t_{2 g} \to e_{g}

(

d-d transition

); the complex shows the

complementary

colour.

[Ti (H_{2} O)_{6}]^{3 +}

(

d^{1}

) absorbs ~498 nm and looks violet;

d^{0}

d^{10}

ions are colourless.

🎯 Exam · Ligand changes the colour

A stronger-field ligand widens

Δ_{o}

, shifting absorption:

[Ni (H_{2} O)_{6}]^{2 +}

(green) →

[Ni (H_{2} O)_{2} (en)_{2}]^{2 +}

(blue/purple) →

[Ni (en)_{3}]^{2 +}

(violet) as

H_{2} O

is replaced by en.

Synergic bonding in metal carbonyls: sigma donation CrightarrowM plus pi back-donation MrightarrowCO. — Synergic bonding in metal carbonyls: $σ$ donation C $\to$ M plus $π$ back-donation M $\to$ CO.

Carbonyl	Shape
$[Ni (CO)_{4}]$	tetrahedral
$[Fe (CO)_{5}]$	trig. bipyramidal
$[Cr (CO)_{6}]$	octahedral
$[M n_{2} (CO)_{10}]$	Mn–Mn bond
$[C o_{2} (CO)_{8}]$	2 bridging CO

★ Remember · Synergic bonding in carbonyls

Two reinforcing parts: a

σ

-bond (C lone pair

\to

empty metal orbital) and a

π

back-bond (filled metal d

\to

empty CO

π^{*}

). They strengthen M–C and weaken C–O. Metal is in a

low/zero

oxidation state, e.g.

[Ni (CO)_{4}]

[Fe (CO)_{5}]

[Cr (CO)_{6}]

Stability (formation) constant

M + 4 L ⇌ M L_{4}, β_{4} = \frac{[ M L _{4} ]}{[ M ] [ L ] ^{4}} = K_{1} K_{2} K_{3} K_{4}

Larger

β

⇒ more stable complex; instability constant

= 1/ β

What raises stability

▸ $Higher metal charge$ , smaller size, and stronger-field ligands.
▸The $chelate effect$ : ring-forming polydentate ligands give very large $β$ .
▸Stepwise constants usually decrease: $K_{1} > K_{2} > K_{3} > K_{4}$ .

Applications

▸ $Analysis$ : EDTA, DMG (dimethylglyoxime) for estimating metal ions; $N a_{2} EDTA$ for water hardness ( $C a^{2 +} /M g^{2 +}$ ).
▸ $Qualitative tests$ : $N i^{2 +}$ + DMG gives a red precipitate; $F e^{3 +}$ + $[Fe (CN)_{6}]^{4 -}$ gives Prussian blue; $C u^{2 +}$ + excess $N H_{3}$ gives deep-blue $[Cu (N H_{3})_{4}]^{2 +}$ .
▸ $Extraction$ : gold/silver via $[Au (CN)_{2}]^{-}$ ; $purification$ : Mond process, $[Ni (CO)_{4}]$ .
▸ $Biology$ : chlorophyll (Mg), haemoglobin (Fe), vitamin $B_{12}$ (Co); medicine: cisplatin.

🚫 Examiner Trap · Examiner traps

(1) Colour is from a

t_{2 g} \to e_{g}

d-d transition

; the observed colour is the COMPLEMENT of the absorbed;

d^{0}

d^{10}

are colourless. (2) Stronger-field ligand

\Rightarrow

larger

Δ_{o}

\Rightarrow

absorbs shorter

λ

. (3)

Synergic

M–CO:

σ

\to

+

π

back-bond (M

\to

π^{*}

); metal in low/zero state. (4)

β_{n} = K_{1} K_{2} \dots K_{n}

; chelates give very large

β

(more stable).

More JEE Main Chemistry formula sheets

Frequently Asked Questions

What are the most important Coordination Compounds formulas for JEE Main?

This Coordination Compounds formula sheet covers all the high-yield Chemistry formulas, definitions and theorems you need for JEE Main, across Introduction to coordination compounds, Werner's theory, Ligands, Coordination number, Denticity — each shown with the key result and, where useful, a worked example.

Is this Coordination Compounds formula sheet free?

Yes — the full chapter formula sheet is free to read online, no login or payment required.

How should I revise Coordination Compounds formulas?

Blurt the Coordination Compounds formulas from memory, then check against this sheet to find your gaps — and practise a few previous-year questions on the chapter to make sure you can apply them under time pressure.

Also useful: all formula sheetsJEE Main previous-year papersmost important chapters.
